ASAS 1ICCT Kanaya

Soal no1:

R4+R5= 1/10 + 1/10

            = 2/10

            = 10/2

            = 5

R2+R45+R6= 5+10+10

                     = 25

Rs= 25+10= 35

Rp= 35×10 : 35+10

    = 7,78

Rtotal= 7,78+10

          = 17,78

I= V/R

 = 10,7/17,78

 = 0,602

ANALISIS phEt

R= 17,78

I= 0,602

R45= 5

Rs= R45+3+R6+R7+R8

   = 5+10+10+10

  = 35

Rp= 35×10 : 35+10

    = 7,78

Rtotal= 7,78+10+10

           = 27,78

I= 0,360

Analisis phEt

Rtotal= 27,78

I= 0,360

R3 + R4 = 3.8 + 10 = 13.8 ohm
R2 paralel R34 = (10 x 13.8) / (10 + 13.8) = 138 / 23.8 = 5.8 ohm
R5 paralel R6 = (10 x 10) / (10 + 10) = 100 / 20 = 5 ohm
R top = 5 + 5 = 10 ohm
R98 = 10 + 5 = 15 ohm
R right = (10 x 15) / (10 + 15) = 150 / 25 = 6 ohm
R total = 10 + 5.8 + 6 = 21.8 ohm

I= 14/21.8 = 0,642

Analisis PhEt

Rtotal= 21.8 oh,

I= 0,642

R total:
Rtotal = 5.37 + 10 = 15.37

Arus total:
I = 11.6 / 15.37 = 0.75 A

R total = 15.37
I total = 0.75 A

Analisis phEt:

I= 0.75
